N.B. Image may vary with product
Are you looking for a powerful motherboard to support your gaming needs?
ASUS TUF GAMING Z790-PLUS WIFI D4 13th Gen & 12th Gen ATX Motherboard With its powerful performance and advanced features, this motherboard is the perfect choice for gaming enthusiasts who demand the best.
In this article, we will dive deep into the features and benefits of the ASUS TUF GAMING Z790-PLUS WIFI D4 13th Gen & 12th Gen ATX Motherboard. We'll explore its technical specifications, performance, and compatibility with the latest hardware and software. So, let's get started!
Intel 13th Gen & 12th Gen processor & Socket LGA1700: The ASUS TUF GAMING Z790-PLUS WIFI D4 13th Gen & 12th Gen ATX Motherboard is compatible with Intel 13th Gen & 12th Gen processors and Socket LGA1700.
4 x DIMM, Max. 128GB, DDR5 7200(OC): This motherboard offers 4 x DIMM slots with a maximum memory capacity of 128GB and DDR5 7200(OC).
1 x DisplayPort, 1 x HDMI port: The ASUS TUF GAMING Z790-PLUS WIFI D4 13th Gen & 12th Gen ATX Motherboard is equipped with 1 x DisplayPort and 1 x HDMI port.
Intel 2.5Gb Ethernet, Wi-Fi 6E: This motherboard is equipped with Intel 2.5Gb Ethernet and Wi-Fi 6E for a fast and reliable connection.
Specifications:
The Best GAMING Z790-PLUS WIFI D4 Motherboard is a powerhouse of performance with its 13th Gen & 12th Gen Intel Core processors. Here are some of its key technical specifications:
Supports 13th Gen & 12th Gen Intel Core processors
Intel LGA 1700 socket
DDR4 4800 MHz memory support
Dual M.2 NVMe SSD slots
WiFi 6E and 2.5G Ethernet
Thunderbolt 4 support
Enhanced power delivery and cooling
Performance:
The Z790-PLUS ATX Motherboard offers outstanding performance and speed. Its advanced features ensure that you get the most out of your gaming experience.
With support for DDR4 4800 MHz memory, you can enjoy lightning-fast performance and multitasking capabilities. The dual M.2 NVMe SSD slots allow you to take advantage of lightning-fast storage speeds.
The motherboard's WiFi 6E and 2.5G Ethernet ensures that you get the fastest internet speeds for online gaming. Additionally, the Thunderbolt 4 support ensures high-speed data transfer for your external devices.
Compatibility:
The ASUS ATX Motherboard is compatible with a wide range of hardware and software. Its LGA 1700 socket ensures compatibility with the latest 13th Gen & 12th Gen Intel Core processors. Additionally, it is compatible with the latest DDR4 memory modules, M.2 NVMe SSDs, and high-speed external devices.
The latest price of ASUS TUF GAMING Z790-PLUS WIFI D4 ATX Motherboard in Bangladesh is ৳ 41000. You can buy the ASUS Z790-PLUS ATX Mottherboard, at the best price from our website or visit any your nearest Binary Logic showroom. Follow us on Facebook For Regular updates & offers.
| Model | TUF GAMING Z790-PLUS WIFI |
| CPU | Intel Socket LGA1700 for 13th Gen Intel Core & 12th Gen Intel Core, Pentium Gold and Celeron Processors* Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0** * Refer to www.asus.com for CPU support list. ** Intel Turbo Boost Max Technology 3.0 support depends on the CPU types. |
| Chipset | Intel Z790 Chipset |
| Memory | 4 x DIMM, Max. 128GB, DDR5 7200(OC)/7000(OC)/6800(OC)/6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600/ 5400/ 5200/ 5000/ 4800 Non-ECC, Un-buffered Memory* Dual Channel Memory Architecture Supports Intel Extreme Memory Profile (XMP) OptiMem II * Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit https://www.asus.com/support/ |
| Graphics | 1 x DisplayPort** 1 x HDMI port*** * Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates. ** Supports max. 4K@60Hz as specified in DisplayPort 1.4. *** Supports 4K@60Hz as specified in HDMI 2.1. **** VGA resolution support depends on processors' or graphic cards' resolution. 1 x DisplayPort** 1 x HDMI® port*** * Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates. ** Supports max. 4K@60Hz as specified in DisplayPort 1.4. *** Supports 4K@60Hz as specified in HDMI 2.1. **** VGA resolution support depends on processors' or graphic cards' resolution. |
| Expansion Slots | Intel 13th & 12th Gen Processors* 1 x PCIe 5.0 x16 slot Intel® Z790 Chipset 1 x PCIe 4.0 x16 slot (supports x4 mode) 1 x PCIe 4.0 x4 slot 2 x PCIe 3.0 x1 slots * Please check the PCIe bifurcation table at the support site (https://www.asus.com/support/FAQ/1037507/). To ensure compatibility of the device installed, please refer to https://www.asus.com/support/ for the list of supported peripherals. |
| Storage | Total supports 4 x M.2 slots and 4 x SATA 6Gb/s ports* Intel 13th & 12th Gen Processors M.2_1 slot (Key M), type 2242/2260/2280/22110 - Intel® 13th & 12th Gen processors support PCIe 4.0 x4 mode Intel® Z790 Chipset M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) M.2_3 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode) M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 & SATA modes) 4 x SATA 6Gb/s ports * Intel Rapid Storage Technology supports PCIe RAID 0/1/5/10, SATA RAID 0/1/5/10. |
| Ethernet | 1 x Intel 2.5Gb Ethernet TUF LANGuard |
| Wireless & Bluetooth | Wi-Fi 6E 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax) Supports 2.4/5/6GHz frequency band* Bluetooth v5.3** * WiFi 6E 6GHz regulatory may vary between countries. ** The Bluetooth version may vary, please refer to the Wi-Fi module manufacturer's website for the latest specifications. |
| USB | Rear USB (Total 8 ports) 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C) 3 x USB 3.2 Gen 2 ports (2 x Type-A + 1 x USB Type-C) 4 x USB 3.2 Gen 1 ports (4 x Type-A) Front USB (Total 7 ports) 1 x USB 3.2 Gen 2 connector (supports USB Type-C) 1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports 2 x USB 2.0 headers support additional 4 USB 2.0 ports |
| Audio | Realtek S1220A 7.1 Surround Sound High Definition Audio CODEC* Impedance sense for front and rear headphone outputs Internal audio Amplifier to enhance the highest quality sound for headphone and speakers Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in) Supports up to 32-Bit/192 kHz playback*" Audio Features Audio Shielding Rear optical S/PDIF out port Premium audio capacitors Dedicated audio PCB layers Audio Cover * Due to limitations in HDA bandwidth, 32-Bit/192 kHz is not supported for 7.1 Surround Sound audio. |
| Back Panel I/O Ports | 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C®) 3 x USB 3.2 Gen 2 ports (2 x Type-A + 1 x USB Type-C®) 4 x USB 3.2 Gen 1 ports (4 x Type-A) 1 x DisplayPort 1 x HDMI® port 1 x Wi-Fi Module 1 x Intel® 2.5Gb Ethernet port 5 x Audio jacks 1 x Optical S/PDIF out port |
| Internal I/O Connectors | Fan and Cooling related 1 x 4-pin CPU Fan header 1 x 4-pin CPU OPT Fan header 1 x 4-pin AIO Pump header 4 x 4-pin Chassis Fan headers Power related 1 x 24-pin Main Power connector 2 x 8-pin +12V Power connectors Storage related 4 x M.2 slots (Key M) 4 x SATA 6Gb/s ports USB 1 x USB 3.2 Gen 2 connector (supports USB Type-C®) 1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports 2 x USB 2.0 headers support additional 4 USB 2.0 ports Miscellaneous 3 x Addressable Gen 2 headers 1 x Aura RGB header 1 x Clear CMOS header 1 x COM Port header 1 x Front Panel Audio header (AAFP) 1 x 20-3 pin System Panel header with Chassis intrude function 1 x Thunderbolt (USB4) header |
| Special Features | ASUS TUF PROTECTION DIGI+ VRM (- Digital power design with DrMOS) ESD Guards TUF LANGuard Overvoltage Protection Safeslot Stainless-Steel Back I/O ASUS Q-Design M.2 Q-Latch PCIe Slot Q-Release Q-DIMM Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) Q-Slot ASUS Thermal Solution M.2 heatsink VRM heatsink design ASUS EZ DIY CPU Socket lever protector ProCool Pre-mounted I/O shield SafeDIMM AURA Sync Aura RGB header Addressable Gen 2 headers |
| Software Features | ASUS Exclusive Software Armoury Crate Aura Creator Aura Sync Fan Xpert 4 (with AI Cooling II) Two-Way AI Noise Cancelation Power Saving AI Suite 3 TurboV EVO DIGI+ VRM PC Cleaner TUF GAMING CPU-Z DTS Audio Processing MyAsus Norton 360 for Gamers WinRAR UEFI BIOS ASUS EZ DIY ASUS CrashFree BIOS 3 ASUS EZ Flash 3 ASUS UEFI BIOS EZ Mode |
| BIOS | 192 (128+64) Mb Flash ROM, UEFI AMI BIOS |
| Manageability | WOL by PME, PXE |
| Accessories | Cables 2 x SATA 6Gb/s cables Miscellaneous 1 x ASUS Wi-Fi moving antenna 1 x TUF GAMING sticker 2 x M.2 Rubber Packages 1 x Screw package for M.2 SSD Documentation 1 x TUF Certification card 1 x User guide |
| Operating System | Windows 11, Windows 10 64-bit |
| Form Factor | ATX Form Factor 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm ) |
Q: What kind of processors does the ASUS TUF GAMING Z790-PLUS WIFI D4 13th Gen & 12th Gen ATX Motherboard support?
A: This motherboard is compatible with Intel 13th Gen & 12th Gen processors and Socket LGA1700.
Q: What kind of RAM does the ASUS TUF GAMING Z790-PLUS WIFI D4 13th Gen & 12th Gen ATX Motherboard support?
A: This motherboard offers 4 x DIMM slots with a maximum memory capacity of 128GB and DDR5 7200(OC).
Q: What is the difference between the 13th Gen & 12th Gen Intel Core processors?
A: The 13th Gen Intel Core processors are the latest processors from Intel, offering advanced performance and features compared to the 12th Gen processors.
Q: What is DDR4 memory, and how does it benefit gaming?
A: DDR4 memory is the latest generation of RAM, offering faster data transfer rates and lower latency compared to older memory types. This results in faster performance and smoother multitasking capabilities, making it ideal for gaming.
Q: Is the ASUS TUF GAMING Z790-PLUS WIFI D4 13th Gen & 12th Gen ATX Motherboard compatible with the latest graphics cards?
A: Yes, the motherboard is compatible with the latest graphics cards from NVIDIA and AMD, ensuring that you can enjoy the latest games with the best graphics
