Gigabyte Z590 UD ATX Motherboard

Intel 10th and 11th Gen
In Stock

Regular Price: ৳ 22,800

Special Cash Price: 20,500

Product Highlights

  • Z590 UD 11th Gen
  • Supports 11th and 10th Gen Intel Core Processors
  • Triple Ultra-Fast NVMe PCIe 4.0/3.0 x4 M.2
  • Dual-Channel DDR4, 4 DIMMs
  • Fast 2.5GbE LAN

Monthly EMI

  • 3 Months EMI - ৳ 7600 Taka
  • 6 Months EMI - ৳ 3800 Taka
  • 9 Months EMI - ৳ 2533 Taka
  • 12 Months EMI - ৳ 1900 Taka
  • Note: Only Available In Branches

Warranty

03 Year Warranty

Home Delivery : Available

Inquiry : [email protected]

CATEGORIES: PC COMPONENTS -> Motherboard -> Gigabyte
BRANDS: Gigabyte

SHARE:    Share


  • Z590 UD 11th Gen
  • Supports 11th and 10th Gen Intel Core Processors
  • Triple Ultra-Fast NVMe PCIe 4.0/3.0 x4 M.2
  • Dual-Channel DDR4, 4 DIMMs
  • Fast 2.5GbE LAN

Gigabyte Z590 UD Intel 10th and 11th Gen ATX Motherboard

Gigabyte Z590 UD Intel 10th and 11th Gen ATX Motherboard supports 11th and 10th Gen Intel Core Series Processors. It supports Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs and Direct 12+1 Phases Digital VRM Solution with 50A DrMOS with Shielded Memory Routing for Better Memory Overclocking. It has an Enlarged VRM Heatsink with Air-Flow Grooving to Increased Surface Contact. It features a Fast 2.5GbE LAN with Bandwidth Management. It comes with Triple Ultra-Fast NVMe PCIe 4.0*/3.0 x4 M.2 with Thermal Guard. It features USB 3.2 Gen2 and Front USB Type-C for Fast and Versatile Connections and Pre-installed IO Shield for Easy and Quick Installation. Supports RGB FUSION 2.0 with Multi-Zone Addressable LED Light Show Design, Support Addressable LED & RGB LED Strips. The Smart Fan 6 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP and Q-Flash Plus Update BIOS without Installing the CPU, Memory, and Graphics Card. It has 3 years warranty.

Basic Information

Supported CPU

11th Generation Intel Core i9 processors / Intel Core i7 processors / Intel Core i5 processors
10th Generation Intel Core i9 processors / Intel Core i7 processors / Intel Core i5 processors / Intel Core i3 processors/ Intel Pentium processors / Intel Celeron processors



Chipset

Intel Z590 Express Chipset



BIOS

1 x 256 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0



Form Factor

ATX Form Factor; 30.5cm x 24.4cm



Audio

Realtek audio CODEC
High Definition Audio
2/4/5.1/7.1-channel
Support for S/PDIF Out



Expansion Slots

PCI

1 x PCI Express x16 slot, running at x16 (PCIEX16)
* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
(The PCIEX16 slot conforms to PCI Express 4.0 standard.)(Note)
1 x PCI Express x16 slot, running at x4 (PCIEX4)
2 x PCI Express x1 slots
(The PCIEX4 and PCIEX1 slots conform to PCI Express 3.0 standard.)



M.2 Socket

1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4 SSD support) (M2P_CPU)(Note)
Chipset:
1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 SATA and PCIe 3.0 x4/x2 SSD support) (M2A_SB)
1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 3.0 x4/x2 SSD support) (M2M_SB)



Memory

Type

Dual-channel memory architecture



Slots

4 x DDR4 DIMM



Supported Memory

11th Generation Intel Core i9/i7/i5 processors:
Support for DDR4 5333(O.C.)/ DDR4 5133(O.C.)/DDR4 5000(O.C.)/4933(O.C.)/4800(O.C.)/ 4700(O.C.)/ 4600(O.C.)/ 4500(O.C.)/ 4400(O.C.)/ 4300(O.C.)/4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2933 / 2800 / 2666 / 2400 / 2133 MHz
10th Generation Intel Core i9/i7 processors:
Support for DDR4 2933/2666/2400/2133 MHz memory modules
10th Generation Intel Core i5/i3/Pentium/Celeron processors:
Support for DDR4 2666/2400/2133 MHz memory modules
4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
Dual channel memory architecture
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Profile (XMP) memory modules



Maximum Memory

128 GB (32 GB single DIMM capacity)



Graphics

Graphics

Integrated Graphics Processor-Intel HD Graphics support:
1 x DisplayPort, supporting a maximum resolution of [email protected] Hz
Support for AMD Quad-GPU CrossFire and 2-Way AMD CrossFire technologies



Connector & Ports

Display Port (s)

1 x DisplayPort, supporting a maximum resolution of [email protected] Hz
* Support for DisplayPort 1.2 version and HDCP 2.3



USB (s)

Chipset:
2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
6 x USB 3.2 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB header)
1 x USB Type-C port with USB 3.2 Gen 1 support, available through the internal USB header
Chipset+2 USB 2.0 Hubs:
6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)



LAN Port (s)

Realtek 2.5GbE LAN chip (2.5 Gbit/1 Gbit/100 Mbit)



Supported Storage

1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4 SSD support) (M2P_CPU)(Note)
Chipset:
1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 SATA and PCIe 3.0 x4/x2 SSD support) (M2A_SB)
1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 3.0 x4/x2 SSD support) (M2M_SB)
5 x SATA 6Gb/s connectors

Support for RAID 0, RAID 1, RAID 5, and RAID 10



Audio

3 x audio jacks



Internal I/O Ports

1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x 4-pin ATX 12V power connector
1 x CPU fan header
4 x system fan headers
2 x addressable LED strip headers
2 x RGB LED strip headers
1 x Q-Flash Plus button
5 x SATA 6Gb/s connectors
3 x M.2 Socket 3 connectors
1 x front panel header
1 x front panel audio header
1 x S/PDIF Out header
1 x USB 3.2 Gen 1 header
1 x USB Type-C header, with USB 3.2 Gen 1 support
2 x USB 2.0/1.1 headers
2 x Thunderbolt add-in card connectors
1 x serial port header
1 x Clear CMOS jumper



TPM (Trusted Platform Module )

1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)



Warranty Information

Manufacturing Warranty

3 years
