Modern Aesthetic Design with Full RGB Lighting Effect
The Premium Series features a modern design, with the enclosure made of SECC steel. The black finish plus the full RGB In Win logo lighting effect will allow users to match with most themed builds.
The Premium Series has a fully RGB logo that radiates the color of your choice. The Premium Series is compatible with 4-pin RGB header(s) found on many ASUS Aura-ready motherboards or other vendors’ RGB-supported motherboards. As long as users activate the software of the motherboard manufacturers, the possibilities are endless.
Smart Fan Control for Optimal Noise Reduction and Cooling Management
The 135mm durable fluid hypro bearing fan not only operates at the fastest speed, but also helps keep the internal components cool. It aims at offering a quiet operating environment for users.
Highly Reliable Japanese Aluminium Electrolytic Capacitors
The Premium Japanese capacitors with 105 °C rating helps stabilize the power at higher temperatures, provide increased longevity, reduce ripple and electrical instabilities and offer better power efficiency.
The fully modular and low-profile cable design let users quickly and easily install without any difficulty
The 135mm durable hypro bearing fan exhausts the generated heat from the power supply, optimizing excellent cooling performance.
Model | PL 650W | PL 750W | PL 850W |
Total Power | 650W | 750W | 850W |
Material | SECC | ||
Type | ATX12V V2.4/ EPS12 V2.92 |
||
Cable Management | Fully Modular | ||
PFC | Active PFC ( > 0.9) | ||
Efficiency | 80 PLUS Gold (up to 90%) | ||
MTBF (Hours) | >100,000hr | ||
AC Input | 100 – 240Vac. 50-60Hz | ||
Hold-up time (ms) | > 16ms | ||
Fan | 135mm Hypro Bearing Fan | ||
Typical Load Fan Noise(dB) | < 25dB | ||
Operating Temperature Range (°C) | 0~50 °C | ||
Full Protection | OCP/ OVP / UVP / SCP / OTP / OPP | ||
Safety Certifications | cTUVus / TUV / CB / BSMI / CE / FCC / EAC / RCM / CCC | ||
Dimensions (L x W x D) |
165 x 150 x 86mm | ||
Connector | 24 Pin Motherboard | 1 | |
8 (4+4) Pin CPU | 2 | ||
8 (6+2) Pin PCI-E | 4 | ||
4 Pin Peripheral | 6 | ||
SATA | 6 | ||
Floppy Power | 2 | ||
RGB LED Controller | 2 | ||
Light | 1 |
