Lan Card LR-Link 1G LREC9222HT Dual Port

In Stock

Regular Price: ৳ 6,100

Special Price: 5,500

Product Highlights

  • LREC9222HT is a PCI Express x1 dual-port RJ45 Connector Gigabit Ethernet network card independently developed by Shenzhen Lianrui Electronics Co., Ltd.
  • based on the Intel I350 chip solution. It is also compatible with PCIe x4, x8, x16 channels.
  • Intel I350 Chipset PCIe x1 Dual Port Network Interface Card ( 2 x RJ45)

Monthly EMI

  • 12 Months EMI - ৳ 508 Taka Taka
  • 9 Months EMI - ৳ 678 Taka Taka
  • 6 Months EMI - ৳ 1,017 Taka Taka
  • 3 Months EMI - ৳ 2,033 Taka Taka
  • Note: Only Available In Branches

Inquiry : [email protected]

CATEGORIES: NETWORK ZONE -> Lan Card

BRANDS: LR-LINK

SHARE:

  • LREC9222HT is a PCI Express x1 dual-port RJ45 Connector Gigabit Ethernet network card independently developed by Shenzhen Lianrui Electronics Co., Ltd.
  • based on the Intel I350 chip solution. It is also compatible with PCIe x4, x8, x16 channels.
  • Intel I350 Chipset PCIe x1 Dual Port Network Interface Card ( 2 x RJ45)

Lan Card LR-Link 1G LREC9222HT Dual Port Price In Bangladesh

LREC9222HT is a PCI Express x1 dual-port RJ45 Connector Gigabit Ethernet network card independently developed by Shenzhen Lianrui Electronics Co., Ltd. based on the Intel I350 chip solution. It is also compatible with PCIe x4, x8, x16 channels. The network card design is primarily used on desktop workstations. The network card can be bundled into groups at the same time through multiple ports to achieve fault tolerance and redundancy to extend network bandwidth and ensure network performance. It can automatically detect and implement communication from the failed port to other members in the same group in real-time, to achieve uninterrupted high-performance communication.
The network card features integrated hardware acceleration to perform TCP/UDP/IP checksum offloading and TCP segmentation tasks. The host processing technology can load the accelerator, and the host processing technology can load the accelerator, which greatly releases the CPU resources and frees up more CPU resources to process other applications. This network card is an ideal solution for applications that deploy workstation networks.
The LREC9222HT was developed on the Intel I350 dual-port Ethernet MAC+PHY (Media Access Controller and Physical Interface Transceiver) controller, allows both ports to operate in full-duplex mode for high-performance network communications in a Gigabit Ethernet connection, bandwidth can be extended by link aggregation and PCI Express channel resources can be saved without consuming bus bandwidth.

Features
Controller Intel I350
Transmission Medium Copper UTP
Cable Type 1000Base-T Cat 5E / Cat6  Or Higher: Up to 100m
100Base-Tx Cat5/Cat 5E/ Cat6 Or Higher: Up to 100m
10Base-T Category 3/4/5/5E/6 Or Higher: Up to 100m
Bracket Low Profile Bracket and Full-height Bracket
Power Dissipation (MAX) 2.0W
Operating system support Windows 10
Windows 8/8.1
Windows 7
Windows Vista
Windows XP
Windows Server 2003
Windows Server 2008 /R2
Windows Server 2012 /R2
Windows Server 2016 /R2
Novell Netware 5.x/6.x or later
Linux kernel version 2.4.x/2.6.x/3.x/4.x or later
FreeBSD 7/8/9 or later
Sun Solaris 9/10/11 or later
VMware ESX/ESXi 4.x/5.x/6.x or later
Connector 2* RJ45
PCIe Bus PCI Express v2.1 (2.5GT/s & 5.0GT/s) x1, Compatible with PCIe x4,x8 or x16
Data Rate Per Port 10Mbps/100Mbps/1000Mbps
Technical Parameters
Ethernet power management Yes
IEEE* 802.3 adaptive Yes
Support adaptation rate 10BASE-T, 100BASE-TX, 1000BASE-T
IEEE Standard / Network topology IEEE 802.3ab 1000BASE-T Gigabit Ethernet



IEEE 802.3u 100base-TX

IEEE 802.3 az
IEEE 802.1Q VLAN

IEEE 802.1ad

PCI-SIG * SR-IOV Support Yes
Jumbo frame support Yes
VMDq Yes
DPDK Support Yes
PXE Support Yes
iSCSI Support Yes
WOL Support Yes
FCoE Support No
Environmental Parameters
Operating Temperature 0 ℃ to 55 ℃ (32 ℉ to 131 ℉)
Storage Temperature -40 ℃ to 70 ℃ (-40 ℉ to 158 ℉)
Storage humidity 35% to 90%, noncondensing
LED Indicators
LED Indicators 1000Mbps: Link Yellow+ Green blinking
Physical Features
PCB Dimension(mm) 104.5*66.8*1.6
Weight (g) 72g
Packing Details
Package Dimension(mm) 179*150*30
2U bracket *1
Installation Guide *1
Warranty Card *1
Gross Weight (g) 171
