N.B. Image may vary with product
Experience the pinnacle of gaming performance with the AORUS EAGLE Motherboard. This cutting-edge motherboard is designed to meet the demands of the most avid gamers, offering a plethora of features to enhance your PC's capabilities.
With the AORUS EAGLE Motherboard, you can unlock the full potential of your gaming setup. Enjoy smooth gameplay, lightning-fast load times, and stunning visuals. Elevate your gaming experience today!
| Component | Details |
|---|---|
| CPU | LGA1851 socket: Support for Intel® Core&trade Ultra Processors L3 cache varies with CPU * Please refer to "CPU Support List" for more information. |
| Chipset | Intel® Z890 Express Chipset |
| Memory | Support for DDR5 8800(O.C) /8600(O.C) / 8400(O.C) /8266(O.C) / 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400 / 6200 / 6000 / 5800 / 5600MT/s memory modules 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of memory Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules Support CUDIMM memory module (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" for more information.) |
| Onboard Graphics | Integrated Graphics Processor-Intel® HD Graphics support: - 1 x USB4® USB Type-C® port, supporting USB4 and DisplayPort video outputs and a maximum resolution of 3840x2160@144 Hz - 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz (Graphics specifications may vary depending on CPU support.) |
| Audio | Realtek® Audio CODEC High Definition Audio 2/4/5.1/7.1-channel * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. |
| LAN | Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
| Wireless Communication | MediaTek Wi-Fi 7 MT7925 (PCB rev. 1.0) Realtek® Wi-Fi 7 RTL8922AE (PCB rev. 1.1) - 802.11a, b, g, n, ac, ax, be, supporting 2.4/5/6 GHz carrier frequency bands - BLUETOOTH 5.4 * Wi-Fi 7 features Windows 11 SV3 to function properly. (There is no support driver for Windows 10.) |
| Expansion Slots | CPU: - 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 Chipset: - 2 x PCI Express x16 slots, supporting PCIe 4.0 and running at x4 |
| Storage Interface | CPU: - 1 x M.2 connector (Socket 3, M key, type 25110/22110/2580/2280 PCIe 5.0 x4/x2 SSD support) Chipset: - 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) |
| USB | CPU: - 1 x USB4® USB Type-C® port on the back panel Chipset: - 1 x USB Type-C® port with USB 3.2 Gen 2 support |
| Internal I/O Connectors | - 1 x 24-pin ATX main power connector - 2 x 8-pin ATX 12V power connectors |
| Back Panel Connectors | - 1 x USB4® USB Type-C® port (DisplayPort) - 2 x USB 3.2 Gen 2 Type-A ports (red) |
| Form Factor | ATX Form Factor 30.5cm x 24.4cm |
