N.B. Image may vary with product
Are you looking for a reliable motherboard to power your 12th or 13th Gen Intel processor?
MSI MAG B760M MORTAR DDR5 mATX Motherboard is designed for durability and performance, and features 4x DDR5 memory slots with a maximum capacity of 192GB, 4x EZ Debug LED, and RAID 0, RAID 1, RAID 5 and RAID 10 support for SATA storage devices. With a Realtek 2.5Gbps LAN and a mATX PCB dimension of 243.84mmx243.84mm, this motherboard is the perfect choice for your gaming setup.
Durability and Performance: The MSI MAG B760M MORTAR DDR5 mATX Motherboard is designed for reliable performance and durability.
Memory: This motherboard has 4x DDR5 memory slots with a maximum capacity of 192GB and supports memory speeds up to 7000+(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz.
LED Feature: This motherboard features 4x EZ Debug LED for easy troubleshooting and diagnostics.
RAID: Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices.
The latest price of MSI MAG B760M MORTAR DDR5 12th 13th Gen mATX Motherboard in Bangladesh is ৳ 26,200. You can buy the MSI MAG B760M MORTAR DDR5 12th 13th Gen mATX Motherboard, at the best price from our website or visit any your nearest Binary Logic showroom. Follow us on Facebook For Regular updates & offers.
| CHIPSET | INTEL B760 |
| CPU SUPPORT | Supports 12th/13th Gen Intel Core Processors, Pentium Gold and Celeron Processors LGA1700 |
| MEMORY | 4x DDR5, Maximum Memory Capacity 192GB Memory Support 7000+(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz Max. overclocking frequency: • 1DPC 1R Max speed up to 7000+ MHz • 1DPC 2R Max speed up to 6600+ MHz • 2DPC 1R Max speed up to 6400+ MHz • 2DPC 2R Max speed up to 5600+ MHz Supports Dual-Channel mode Supports non-ECC, un-buffered memory Supports Intel® Extreme Memory Profile |
| ONBOARD GRAPHICS | 1x HDMI Support HDMITM 2.1 with HDR, maximum resolution of 4K 60Hz* 1x DisplayPort Support DP 1.4, maximum resolution of 4K 60Hz* *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed. |
| EXPANSION SLOT | 2x PCI-E x16 slot Supports x16/x4 1x PCI-E x1 slot PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) |
| STORAGE | 2x M.2 M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices 4x SATA 6G |
| RAID | Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices |
| USB | 4x USB 2.0 (Rear) 4x USB 2.0 (Front) 2x USB 3.2 Gen1 Type A (Front) 3x USB 3.2 Gen2 Type A (Rear) 1x USB 3.2 Gen2 Type C (Front) 1x USB 3.2 Gen2x2 Type C (Rear) LAN Realtek® 2.5Gbps LAN AUDIO Realtek® ALC897 Codec 7.1-Channel USB High Performance Audio Supports S/PDIF output |
| INTERNAL I/O | 1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x CPU Fan 1x Pump Fan 4x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x TBT connector (JTBT, supports RTD3) 1x Tuning Controller connector(JDASH) 2x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 2x USB 3.2 Gen1 Type A ports 1x USB 3.2 Gen2 Type C ports |
| LED FEATURE | 4x EZ Debug LED |
| OPERATING SYSTEM | Support for Windows 11 64-bit, Windows 10 64-bit |
| PCB DIMENSION | mATX 243.84mmx243.84mm |
Q: What type of processor does the MSI MAG B760M MORTAR DDR5 mATX Motherboard support?
A: This motherboard supports 12th and 13th Gen Intel Processors (LGA1700).
Q: What is the maximum memory capacity of the MSI MAG B760M MORTAR DDR5 mATX Motherboard?
A: The maximum memory capacity is 192GB.
Q: Does the MSI MAG B760M MORTAR DDR5 mATX Motherboard support RAID?
A: Yes, it supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices.
