Intel B760 Chipset: Powered by the Intel B760 chipset, this motherboard delivers a robust foundation for high-performance gaming and computing.
CPU Support: Designed for 12th/13th Gen Intel Core processors, Pentium® Gold, and Celeron Processors, LGA 1700.
Memory Support: Up to DDR4 with a maximum memory capacity of 128GB, supporting a wide range of overclocking frequencies for optimal performance.
Onboard Graphics: HDMI 2.1 and DP 1.4 support with a maximum resolution of 4K 60Hz, catering to the visual demands of modern gaming.
Expansion Slots: 5x PCI-E x16 slots for versatile connectivity and GPU configurations, ensuring compatibility with the latest graphics cards.
Storage Options: Dual M.2 slots (PCIe 4.0 x4 and PCIe 4.0 x4 / SATA mode), along with 4x SATA 6G ports and RAID support for flexible storage solutions.
USB Connectivity: A plethora of USB ports, including USB 2.0, USB 3.2 Gen1 Type A/C, and USB 3.2 Gen2 Type A/C, for seamless connectivity.
Networking: Realtek RTL8125BG 2.5G LAN and Intel Wi-Fi 6E for high-speed and reliable wired/wireless connections.
Audio Experience: Realtek ALC897 Codec for 7.1-Channel High Definition Audio, delivering an immersive gaming audio experience.
Internal I/O Connectivity: Multiple power connectors, fan headers, USB ports, RGB LED connectors, and more for easy customization and expansion.
LED Feature: 4x EZ Debug LED for quick diagnostics during system troubleshooting.
Back Panel Ports: Diverse back panel ports, including 2.5G LAN, Wi-Fi/Bluetooth, HDMI™, USB 3.2 Gen 2, DisplayPort, and more.
Operating System Compatibility: Supports Windows 11 64-bit and Windows 10 64-bit for the latest gaming and computing experiences.
PCB Dimension: ATX form factor with dimensions of 243.84mm x 304.8mm for compatibility with a variety of gaming cases.
The latest price of MSI PRO B760-P WIFI DDR4 13th Gen & 12th Gen ATX Motherboard in Bangladesh is ৳ 22,500. You can buy the MSI PRO B760-P WIFI DDR4 13th Gen & 12th Gen ATX Motherboard, at the best price from our website or visit any your nearest Binary Logic showroom. Follow us on Facebook For Regular updates & offers.
Upgrade Your PC with MSI PRO B760-P WIFI DDR4 13th Gen & 12th Gen ATX Motherboard from Binary Logic - Bangladesh's Best Motherboard Shop.
Build your Desktop Computer From Binary Logic. Binary Logic is the best gaming pc, graphics pc, video editor pc, and content creator pc builder in Bangladesh since 2001.
Here you will get intel desktop processor, desktop pc case, ram,SSD and any kinds of pc components at the best affordable price in Bangladesh
|CPU SUPPORT||Supports 12th/13th Gen Intel Core
Processors, Pentium® Gold and Celeron Processors
|MEMORY||x DDR4, Maximum Memory Capacity 128GB
Memory Support 5333(OC)/ 5200(OC)/ 5066(OC)/
5000(OC)/ 4800(OC)/ 4600(OC)/ 4400(OC)/
4266(OC)/ 4200(OC)/ 4000(OC)/ 3800(OC)/
3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/
3333(OC)/ 3200(JEDEC)/ 2933(JEDEC)/
2666(JEDEC)/ 2400(JEDEC)/ 2133(JEDEC)
Max. overclocking frequency:
• 1DPC 1R Max speed up to 5333+ MHz
• 1DPC 2R Max speed up to 4800+ MHz
• 2DPC 1R Max speed up to 4400+ MHz
• 2DPC 2R Max speed up to 4000+ MHz
Supports Dual-Channel mode
Supports non-ECC, un-buffered memory
Supports Intel® Extreme Memory Profile (XMP)
|ONBOARD GRAPHICS||Support HDMI™ 2.1, maximum resolution of 4K 60Hz*
Support DP 1.4, maximum resolution of 4K 60Hz*
*Available only on processors featuring
integrated graphics. Graphics specifications
may vary depending on the CPU installed.
|EXPANSION SLOT||5x PCI-E x16 slot
PCI_E1 PCIe 4.0 supports up to x16 (From CPU)
PCI_E2 PCIe 3.0 supports up to x1 (From Chipset)
PCI_E3 PCIe 4.0 supports up to x16 (From Chipset)
PCI_E4 PCIe 3.0 supports up to x1 (From Chipset)
PCI_E5 PCIe 3.0 supports up to x1 (From Chipset)
|STORAGE||2x M.2 slot
M.2_1 (From CPU) supports up to PCIe 4.0 x4 ,
supports 22110/2280/2260/2242 devices
M.2_2 (From Chipset) supports up to PCIe
4.0 x4 / SATA mode, supports 2280/2260/2242 devices
4x SATA 6G port
* SATA8 will be unavailable when
installing M.2 SATA SSD in the M2_2 slot.
|RAID||Supports RAID 0, RAID 1, RAID 5
and RAID 10 for SATA storage devices
|USB||4x USB 2.0 (Rear)
4x USB 2.0 (Front)
2x USB 3.2 Gen1 Type A (Front)
1x USB 3.2 Gen1 Type C (Front)
2x USB 3.2 Gen2 Type A (Rear)
1x USB 3.2 Gen2 Type C (Rear)
|LAN||Realtek RTL8125BG 2.5G LAN|
|WIRELESS / BLUETOOTH||Intel Wi-Fi 6E
The Wireless module is pre-installed in the M.2 (Key-E) slot
Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (160MHz) up to 2.4Gbps
Supports 802.11 a/ b/ g/ n/ ac/ ax
Supports Bluetooth 5.3, FIPS, FISMA
* Wi-Fi 6E 6GHz may depend on every country’s
regulations and will be ready in Windows
10 build 21H1 and Windows 11.
|AUDIO||Realtek ALC897 Codec
7.1-Channel High Definition Audio
|INTERNAL I/O||1x Power Connector(ATX_PWR)
2x Power Connector(CPU_PWR)
1x CPU Fan
1x Pump Fan
5x System Fan
2x Front Panel (JFP)
1x Chassis Intrusion (JCI)
1x Front Audio (JAUD)
1x Printer Port (JLPT)
1x Com Port (JCOM)
1x TBT connector (JTBT, supports RTD3)
2x Addressable V2 RGB LED connector (JARGB_V2)
1x RGB LED connector(JRGB)
1x TPM pin header(Support TPM 2.0)
4x USB 2.0
2x USB 3.2 Gen1 Type A
1x USB 3.2 Gen1 Type C
|LED FEATURE||4x EZ Debug LED|
|BACK PANEL PORTS||Keyboard / Mouse
Wi-Fi / Bluetooth
USB 3.2 Gen 2 10Gbps (Type-A)
USB 3.2 Gen 2 10Gbps (Type-C)
|OPERATING SYSTEM||Support for Windows 11 64-bit,
Windows 10 64-bit
Q: Does this motherboard support the latest Intel processors?
A: Yes, the MSI PRO B760-P WIFI DDR4 motherboard is designed to support 12th/13th Gen Intel Core processors, Pentium® Gold, and Celeron Processors with LGA 1700 sockets.
Q: What is the maximum memory capacity and supported memory frequencies?
A: The motherboard supports up to 128GB of DDR4 memory with a wide range of overclocking frequencies, including 5333(OC), 5200(OC), and more.
Q: Can I use multiple graphics cards with this motherboard?
A: Yes, the motherboard features 5x PCI-E x16 slots, allowing for multiple graphics card configurations to enhance gaming performance.
