NUC PC Intel i7 NUC9i7QNX 9th GEN Extreme Kit

In Stock

Regular Price: ৳ 115,600

Special Price: 104,000

Product Highlights

  • 2.6 GHz Intel Core i7-9750H 6-Core
  • 2 x DDR4-2666 Slots (Up to 64GB)
  • 3 x M.2 PCIe x4 Slots
  • Integrated Intel UHD Graphics 630
  • SDXC Media Card Reader
  • Dual Gigabit Ethernet
  • Wi-Fi 6 (802.11ax) | Bluetooth
  • Thunderbolt 3 | HDMI 2.0a
  • Windows 10 Compatible

Warranty

3-Year Warranty

Home Delivery : Available

Inquiry : [email protected]

CATEGORIES: DESKTOP PC -> INTEL NUC

BRANDS: Intel

SHARE:

  • 2.6 GHz Intel Core i7-9750H 6-Core
  • 2 x DDR4-2666 Slots (Up to 64GB)
  • 3 x M.2 PCIe x4 Slots
  • Integrated Intel UHD Graphics 630
  • SDXC Media Card Reader
  • Dual Gigabit Ethernet
  • Wi-Fi 6 (802.11ax) | Bluetooth
  • Thunderbolt 3 | HDMI 2.0a
  • Windows 10 Compatible

Configure your own compact gaming build with the Intel NUC 9 NUC9i7QNX Extreme Kit. This kit houses a 9th Gen 2.6 GHz Intel Core i7-9750H 6-Core processor, which can be boosted up to 4.1 GHz. Add your own RAM, up to 64GB 2666 MHz DDR4, via the two memory slots. For storage, you can add two M.2 SSDs and an M.2 NVMe supported SSD. While visuals are handled by integrated Intel UHD Graphics 630, you can opt for a dedicated GPU with the double-wide PCIe 3.0 x16 slot, which supports a graphics card with a max length of 8". There are also two Thunderbolt 3 ports, which have a maximum throughput of 40 Gb/s. The SDXC media card reader allows you to transfer photos, videos, and other files. There is also dual Gigabit Ethernet RJ45 LAN jacks for a wired internet connection. However, you can go wireless, thanks to Wi-Fi 6 (802.11ax) support. You can also connect wirelessly to supported peripherals and accessories with Bluetooth 5.0. Don't forget to install your own copy of Windows 10 or Linux on this computer.

9th Gen Intel Core i7 Performance

The Intel NUC 9 Extreme Kit features an Intel Core i7-9750H processor. Its six cores reach a stock speed of 2.6 GHz and can be boosted up to 4.5 GHz.

Wi-Fi 6 (802.11ax)

Wi-Fi 6 (802.11ax) is the next-gen Wi-Fi standard, improving a variety of features including data rates, capacity, performance in dense environments, and power efficiency.

Expansion Options

The Intel NUC 9 Extreme Kit has three M.2 slots as storage options. For RAM, there are two memory slots for 2666 MHz DDR4 slots.

Thunderbolt 3

Thunderbolt 3 is a hardware interface that utilizes the reversible USB Type-C connector. Doubling the speed of its predecessor, Thunderbolt 3 features a maximum throughput of 40 Gb/s when used with compatible devices. The connector also transmits data via USB 3.1 at up to 10 Gb/s, and dual-bandwidth DisplayPort 1.2 allows you to connect up to two 4K displays simultaneously. Additionally, you can daisy chain up to six devices from a single Thunderbolt 3 port.

Performance

CPU Socket BGA 1440
CPU 2.6 GHz Intel Core i7-9750H 6-Core
Maximum Boost Speed 4.5 GHz
L3 Cache 12 MB
Memory Type 2666 MHz DDR4
Total Installed Memory None
Maximum Memory Capacity 64 GB
Memory Slot Type Not Specified by Manufacturer
Memory Slots 2 (2 Available)
Graphics Type Integrated
GPU Intel UHD Graphics 630

Storage and Expansion

SSD Slots 3 x M.2 PCIe x4
Total Installed Capacity 0 GB
PCI Expansion 1 x PCIe 3.0 x16
1 x PCIe 3.0 x4
Optical Drive None

I/O

Ports 6 x USB Type-A (USB 3.1 / USB 3.2 Gen 2)
USB Type-C Ports 2 x Thunderbolt 3
Display 1 x HDMI 2.0a
Audio 1 x 1/8" / 3.5 mm Headphone Output
Built-In Speakers None
Built-In Microphones None
Media Card Slots 1 x SD/SDHC/SDXC (UHS-II [312 MB/s])

Communications

Ethernet 2 x RJ45 (Gigabit)
Wi-Fi Wi-Fi 6 (802.11ax)
MU-MIMO Support Yes
Bluetooth Yes
NFC No

Keyboard & Mouse

Keyboard None
Pointing Device None

General

Security Kensington Lock Slot
Dimensions 9.37 x 8.5 x 3.78" / 238 x 216 x 96 mm
Warranty Length Limited 3-Year Warranty
