Description

Biostar H510MX/E 2.0 Ver. 6.0 11th GEN Motherboard



  • Supports 10th/11th Generation Intel Core™ Processor
  • Intel H510 single chip architecture
  • Supports 2-DIMM DDR4- 3200/ 2933/ 2666/ 2400/2133/ 1866 up to 64 GB Memory
  • Supports PCIe 4.0
  • Supports PCIe M.2 3.0 (32Gb/s)
  • Supports USB 3.2 Gen1
  • Supports WiFi 6 module (No WiFi 6 card included)

Intel Core i3-10100F 3.6 GHz Quad-Core LGA 1200 Processor

  • 4 Cores & 8 Threads
  • 3.6 GHz Clock Speed
  • 4.3 GHz Maximum Turbo Frequency
  • LGA 1200 Socket

G Skill Ripjaws V 8GB 2666 MHz Desktop DDR4 RAM

  • 8GB Capacity
  • 2666 MHz Clock Speed
  • Tested Latency 15-15-15-35
  • Intel XMP 2.0 (Extreme Memory Profile) Ready

Biostar M700 Series 256GB M.2 Nvme SSD

  • M700 series 256GB SSD
  • BIOSTAR Unique Design
  • Standard M.2 2280 Form Factor
  • PCI-Express Gen3x4 interface
  • Support NVMe v1.3
  • Support AES256
  • End-to-End data protection

ARKTEK GT610 2G DDR3 64Bit Low Profile Graphics Card

  • GPU Geforce GT610
  • Graphics Memory Type GDDR3
  • Graphics Interface VGA\ DVI\ HDMI
  • Memory Bus 64 bit
  • VGA Card Interface PCI-E
  • VGA Card Memory 2GB DDR3

Intopic KCW-950 2.4GHz Wireless Keyboard Mouse Combo



  • Mouse: UFO-MSW-950
  • NANO receiver can be stored in mouse body.
  • 2.4GHz auto-link technology and ergonomic design, The use of distance 7-10 meters.
  • Independent DPI button to quickly switch DPI with 3 levels: 800/1200/1600
  • Standard key configuration, Chinese / English / Cangjie keyboard
  • Keyboard:KBW-KBW-939
  • Keycap laser engraving characters have strong wear resistance and are not easy to fade
  • Low-voltage lights design, remind replace batteries.
  • 12 sets of composite multimedia key design



FAQs?



What is the price of binary Logic Work PC 10100F in bd at binary logic?

The special cash price of Binary Logic Work PC 10100F in bd at binary logic is ৳ 32,500 only. you can buy the Binary Logic Work PC 10100F at the best price from our website or visit your nearest Binary Logic showroom. Follow us on Facebook for regular updates and offers.


Specification

Biostar H510MX/E 2.0 Ver. 6.0 11th GEN Motherboard

Chipset

Intel H510

CPU SUPPORT

Support for 10th/ 11th Generation Intel Core i9/ i7/ i5/ i3 processors and Intel Pentium processors/ Intel Celeron processors in the LGA1200 package
* Please refer to www.biostar.com.tw for the CPU support list.

MEMORY

Supports Dual Channel DDR4 3200/ 2933/ 2666/ 2400/ 2133/ 1866
2 x DDR4 DIMM Memory Slot, Max. Supports up to 64 GB Memory
Each DIMM supports non-ECC 4/8/16/32GB DDR4 module
* Please refer to www.biostar.com.tw for the Memory support list.

INTEGRATED VIDEO

By CPU model
Supports DX12
Supports HDCP
Supports HDMI 1.4 version

STORAGE

-- Total supports 1 x M.2 socket and 4 x SATA III (6Gb/s) ports
4 x SATA III Connectors (6Gb/s)
1 x M.2 (M Key) Socket:
Supports M.2 Type 2242/ 2260/ 2280 SSD module.
Supports PCIe 3.0 x4 (32Gb/s) - NVMe/ AHCI SSD & SATA III (6Gb/s) SSD
* When using the SATA SSD module on M.2 slot (M2_PCIEG3_32G_SATA_1), the SATA_1 connector will be disabled.

LAN

Intel I219V
10/ 100/ 1000 Mb/s auto-negotiation, Half / Full duplex capability

AUDIO CODEC

ALC897
7.1 Channels, High Definition Audio

USB

4 x USB 3.2(Gen1) ports (2 on rear I/Os and 2 via internal headers)
8 x USB 2.0 ports (4 on rear I/Os and 4 via internal headers)

EXPANSION SLOT

1 x PCIe 3.0 x1 Slot
1 x PCIe 3.0/ 4.0 x16 Slot (x16 mode)
* The PCIe 4.0 only depends on Rocket Lake CPUs.

REAR I/O

2 x WIFI Antenna Ports
1 x PS/2 Keyboard / Mouse
1 x HDMI Port
1 x VGA Port
1 x DVI-D port
2 x USB 3.2 (Gen1) Ports
4 x USB 2.0 Port
1 x LAN port
3 x Audio Jack

INTERNAL I/O

4 x SATA III Connectors (6Gb/s)
1 x M.2 (E Key) Socket: Supports 2230 type Wi-Fi & Bluetooth module and Intel CNVi
2 x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1 x USB 3.2 (Gen1) Header (each header supports 2 USB 3.2 (Gen1) ports)
1 x 8-Pin Power Connector
1 x 24-Pin Power Connector
1 x CPU Fan Connector
1 x System Fan Connector
1 x Front Panel Header
1 x Front Audio Header
1 x Internal Stereo Speaker Header
1 x Clear CMOS Header
1 x COM Port Header
* M.2 (E key) Wi-Fi card is not provided

H/W MONITORING

CPU / System Temperature Monitoring
CPU / System Fan Monitoring
Smart / Manual CPU Fan Control
System Voltage Monitoring

DIMENSION

Micro ATX Form Factor Dimension: 20.8 cm x 23.6 cm ( W x L )

OS SUPPORT

Supports Windows 10(64bit)
※Biostar reserves the right to add or remove support for any OS with or without notice.

BUNDLE SOFTWARE

BullGuard

ACCESSORIES

2 x SATA Cable
1 x I/O Shield
1 x DVD Driver
1 x Quick Guide
1 x WiFi accessories

FEATURES

BIOS-Flasher



Intel Core i3-10100F 3.6 GHz Quad-Core LGA 1200 Processor

Basic Information
Brand Intel
Model

i3-10100

Base Frequency 3.60 GHz
Maximum Turbo Frequency 4.30 GHz
Cache

6 MB SmartCache

Cores 4
Threads 8
Default TDP 65 W
Memory Specifications
Maximum Size

128 GB

Maximum Speed 41.6 GB/s
Type DDR4-2666
Max Number of Channels 2
Graphics Specifications
Processor Graphics

Intel UHD Graphics 630

Base Frequency 350 MHz
Max Dynamic Frequency 1.10 GHz
Max Video Memory

64 GB

Max Resolution Max Resolution (HDMI 1.4): 4096 x 2160 @30Hz
Max Resolution (DP): 4096 x 2304 @60Hz
Max Resolution (eDP - Integrated Flat Panel): 4096 x 2304 @60Hz
Warranty Information
Manufacturing Warranty 03 Years



G Skill Ripjaws V 8GB 2666 MHz Desktop DDR4 RAM



Model



Brand

G.SKILL

Series

Ripjaws V Series

Model

F4-2666C15D-8GVR





Capacity

8GB (2 x 4GB)

Type

288-Pin DDR4 SDRAM

Speed

DDR4 2666 (PC4 21300)

CAS Latency

15

Timing

15-15-15-35

Voltage

1.20V

ECC

No

Buffered/Registered

Unbuffered

Multi-channel Kit

Dual Channel Kit

Chipset

Intel Z170 Platform / Intel X99 Platform

Color

Red

Heat Spreader

Yes

Features

Extreme performance DDR4 memory designed for gaming and PC enthusiasts

Optimized compatibility with DDR4-compatible Intel Core platforms

Sleek and stylish aluminum heat spreader design

1.2V ultra-low voltage

Intel XMP 2.0 support

Recommend Use

High Performance or Gaming Memory





Biostar M700 Series 256GB M.2 Nvme SSD



Capacity

256GB

Interface

PCI-E Gen3 x4

Form Factor 2280 M.2
Dimension 22 x 80 x 3.5 mm
Operating Voltage DC 3.3V
Max. Read 1850MB/s
Max. Write

950MB/s

Operating Temperature 0~70°C
Operation Systems Windows/Linux/Mac





ARKTEK GT610 2G DDR3 64Bit Low Profile Graphics Card



Graphics Engine

GeForce GT610 2GB

Stream Processors

GF119-300-A1/ 48SP

GPU /Boost Clock

810MHz

Memory Clock

1000MHz

Memory Type

DDR3

Memory Size

2GB

Memory Bus

HDMI, DVI, VGA

Outputs

No

Power Connector

2.0

PCI Express

11

DirectX Support

300W

Recommend PSU

300W

Maximum GPU
Temperature (in C)

102



Intopic KCW-950 2.4GHz Wireless Keyboard Mouse Combo



ˇInterface :

USB 2.0

ˇSensor report rate  :

3000 times per second

ˇSensor Tracking Speed :

28  inches/second

ˇAcceleration :

10G

ˇOperating angle :

360 degrees

ˇOperating distance :

7~10  meter

ˇMouse LED  :

Red  Led

ˇReceiver power :

5V ± 0.25V

ˇMouse working voltage :

1.5 V

ˇMouse working current  :

15 mA

ˇKeyboard working voltage:

3.0 V

ˇKeyboard working current :

5 mA

ˇDimension:

Mouse :

L= 104mm  W= 60 mm  H= 38mm


Keyboard :



L= 423mm  W= 132.7 mm H= 30 mm
  Receiver  :  L= 18 mm W= 14mm H=5.5 mm

 ˇWeight :

Mouse :

63  ± 3 g   (Without battery)


Keyboard :



450  ± 0.5 g  (Without battery)
  Receiver :  2  ± 0.5 g

ˇButtons :





Mouse   :  3 buttons with scroll wheel  DPI
  Keyboard  :   104 buttons
